Passive Approaches to Low-Energy Affordable

Passive low-energy design principles can be used with various construction practices, methods, and materials. The “best” choices often depend on where a project is located, the building type and design, current material prices, and the experience and preferences of the builder or developer.

In general, however, many of the passive, low-energy affordable housing projects tended to feature common design elements and attributes, such as:
● high-performance wall systems with high levels of blown or sprayed insulation; 38×89-mm (2×4-inch) or 38×140-mm (2×6-inch) wood-frame construction with significant exterior rigid foam insulation; or structural insulated panels (SIPs);
● a focus on eliminating thermal bridges through the building envelope to minimize heat loss;

● strategically placed, high-performance triple-glazed windows with inert gas fill, thermally broken and insulated frames, warm edge spacers, low-emissivity coatings, multiple airtight seals, and external shading;
● an airtight building envelope with a minimum airtightness of 0 .6 ACH50; and
● heat recovery or energy recovery ventilators (HRVs or ERVs) to improve indoor air quality while saving energy and lowering costs.
